Descriptive abstract
This series could do work of measuring, can holding, and filling ,etc, it can constitute the whole set can filling work line with other related machines, and suitable for filling kohl, glitter powder, pepper, cayenne pepper, milk powder, rice flour, albumen powder, soy milk powder, coffee powder, medicine powder ,additive, essence and spice, etc.

Main features
Stainless steel structure, level split hopper, easily to wash.
Servo-motor drive auger. Servo-motor controlled turntable with stable performance.
PLC, touch screen and weighing module control.
With adjustable height-adjustment handwheel at reasonable height, easy to adjust the head position.
With pneumatic can lifting device to assure the material not spilling out when filling.
Weight-chosen device, to assure each product be qualified, so to leave the latter cull eliminator.
To save all product’s parameter formula for later use, save 10 sets at most.
When changing the auger accessories, it is suitable for materials ranging from super fine powder to small granula.

Main Technical Data

Model	JN-SR-DA	JN-SR-DB
Container Size	φ20-100mm, H 15-150mm	φ30-160mm , H50-260mm
Filling Weight	1 – 500g	10 – 5000g
Filling Accuracy	≤ 100g, ≤±2%; 100 – 500g，≤±1%	≤ 500g, ≤±1%; >500g, ≤±0.5%
Filling Speed	40 - 80 bottles/min	40 - 80 bottles/min
Power Supply	3P  AC208-415V  50/60Hz	3P  AC208-415V  50/60Hz
Air Supply	6 kg/cm2 0.1m3/min	6 kg/cm2 0.1m3/min
Total Power	3.52Kw	4.42Kw
Total Weight	700kg	900kg
Overall Dimensions	1770×1320×1950mm	2250×2250×2425mm
Hopper Volume	25L	50L
